    The newest Computerized multi needle quilting machine with 1500 rpm

    Ask Lasest Price
    Brand Name : ZOLYTECH
    Model Number : WV15
    Certification : CE
    Price : USD 55000-65000 PCS
    Supply Ability : 30 /PCS /MONTH
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    The newest Computerized multi needle quilting machine with 1500 rpm

    Technical parameters


    dimension (L*W*H)5400*1650*2050mm
    weight5500kg
    quilting width2450mm
    needle bar distance50.8, 76.2,127. 76.2,152.4
    needle distance25.4mm
    x-axis movement displacement304.8mm
    quilting thickness80mm
    stitch length3-7mm
    capacity80-350 m/hour
    needle type24/180 23/160 22/140 21/130
    main shaft speed600-1500 rpm
    voltage380v/50hz, 220v/60hz,3-phase
    power11kw

    Advantages :


    High speed Computerized multi needle quilting machine with 1500 rpm is mainly used for making mattress ,jackets,sleeping bags,quilt etc. China quilting machine working at high speed without any virabtion. Strong and rigid machine body,good quality quilting and lower noise.


    Extreme precision with 360 intricated patterns including bartack and jump patterns with automatic

    top thread cut.


    This machine has the automatic lubrication system ( that work on anti friction component, ball screw and linear guideway) enables labor saving and long life of the machine.


    Optional : slitting system, precisely slitting after quilting for making mattress tape.


    Japanese famous brand bearing and precise casting spare parts are used on the machine, which ensures long life of the machine.


    Delta VFD (variable-frequency driver) drives main shaft (Z shaft ) and panasonic servo driver & motor control the saddle and roller.


    Automatic detection of machine running condition.




    Quality The newest Computerized multi needle quilting machine with 1500 rpm for sale
