Computerized Multi Needle Industrial Quilting Machine Windows Operating System

Dominent Features:

Needle bar and plate adopt double rocker mechanical manufacturing process, avoid the lube and dirty the fabric effectively.

Automatic stop when up or bottom thread is broken, and both up and down safety infrared protection.

Delta VFD (variable-frequency driver) drives main shaft (Z shaft), Panasonic servo driver & motor control the saddle (X shaft) and roller (Y shaft).

Both serial patterns and Tack & Jump patterns (360° and 180°) are available.

Controlling system based on Windows, CAD drawing.

Automatic stop when pre-set processing length is finished, which is saving labor and easy operation.

Automatic detection of machine running condition.

Stronger machine body makes it run more silently and stably.

Technical Datas:

Dimension (l*w*h): 5400*1650*2050mm
Weight: 4000kg
Quilting width: 2450mm
Needle bar distance: 50.8, 76.2, 127mm (5’’)
76.2, 76.2, 152.4mm (6’’)
Needle distance: 25.4mm
X-axis movement displacement: 304.8mm
Quilting thickness: ≤80mm
Stitch length: 3-7mm
Capacity: 60-230 (m/hour)
Needle type: 24/180 23/160 22/140 21/130
Main shaft speed: 300-800rpm
Voltage: 380v/50hz 220v/60hz, 3-phase
Power: 7kw

Pattern Collection:

Zolytech Machinery Co., Ltd located in Dongguan city is an Hi-Tech enterprise, which is professional in manufacturing mattress machines. At present, our main products include Computerized Chain Stitch Multi-Needle Quilting Machine, Computerized Lock Stitch Multi-Needle Quilting Machine, Panel Cutter Machine, Automatic Spring Coiling Machine, Automatic Spring Assembling Machine, etc.

After more than 10 years’ development, we have brought in advanced production line, and built up complete quality control system, professional global sales network and after service system. We have obtained ISO 9001:2000 certificate and all our products have passed the CE certificate.

We have built up one outstanding R&D team which is strong in both machinery and software R&D, focusing on the profound development in production for adapting the latest technology to our machines.

And we also have built up a professional international sales team and an 24 hours on-line after service team, thus we can provide prompt technical support and after service for the customers around the world.

We have enjoyed a high reputation in the world with its high efficiency, easy operation and steady performance. The products have been sold abroad to Asia, Europe, America, Africa and Middle East, etc.

Excellent quality management, prompt after-sales service, ongoing innovation are our permanent pursuit. We will continue to work with input from customers, so as to continue to make the better machines for the future.
